Stainless Steel Flexible Coupling Style 12S
Specifications
| Model | Stainless Steel Grooved Product |
|---|---|
| Connection | Grooved |
| Temperature | -30 - +230F |
| Pressure | Up to 300 PSI |
| Standards | AWWA C-606 |
Got questions?
Feel free to get in touch
Flexible stainless steel grooved coupling for controlled pipe movement.
Functionality of the Product
• Allows controlled expansion and contraction of piping
• Accommodates angular and rotational movement
• Absorbs vibration, noise, and system settlement
Material of Construction
Housing: Stainless Steel (SS 304)
Bolts & Nuts: Stainless Steel
Gasket: Compatible gasket materials for service conditions
Approvals
UL Listed
FM Approved
Standards of Product
Designed for grooved stainless steel piping systems
Allows pipe support and hanging in accordance with ANSI B31.1
Usage of Product
Used in stainless steel piping systems requiring flexibility
Suitable for areas with vibration, movement, or thermal variation
Pressure Details
Pressure ratings conform to standard grooved coupling requirements for stainless steel piping systems. Contact OEM for rated pressure.
Finish of Material
Natural stainless steel finish
