Stainless Steel Rigid Coupling Style 05S
Specifications
| Model | Stainless Steel Grooved Product |
|---|---|
| Connection | Grooved |
| Temperature | -30 - +230F |
| Pressure | Up to 300 PSI |
| Standards | AWWA C-606 |
Got questions?
Feel free to get in touch
Rigid stainless steel grooved coupling for fixed pipe joints.
Functionality of the Product
• Provides a rigid joint with no angular or linear movement
• Prevents pipe expansion, contraction, and deflection
• Tongue and groove design ensures positive pipe alignment
Material of Construction
Housing: Stainless Steel (SS 304)
Bolts & Nuts: Stainless Steel
Gasket: Compatible gasket materials for service conditions
Approvals
UL Listed
FM Approved
Standards of Product
Designed for grooved stainless steel piping systems
Allows pipe support and hanging in accordance with ANSI B31.1
Usage of Product
Used where rigid pipe joints are required
Suitable for vertical and horizontal stainless steel piping installations
Pressure Details
Pressure ratings conform to standard grooved coupling requirements for stainless steel piping systems. Contact OEM for rated pressure.
Finish of Material
Natural stainless steel finish
